Being Foshan LED Airotor 401P-B2

Being Foshan LED Airotor 401P-B2

Being Foshan LED Airotor 401P-B2 is a high-performance dental handpiece designed for efficiency, comfort, and durability. Its LED illumination provides better visibility, while the push-button mechanism ensures easy bur changing. The high-density cartridge delivers high cutting efficiency with minimal vibration and noise. The newly designed handle is comfortable to hold and easy to clean, and the handpiece is fully autoclavable.

Features

• Push-button type for easy bur changing
• LED illumination for better visibility and angle, improving efficiency
• High-density cartridge with high cutting efficiency, low vibration, and low noise
• Ergonomically designed handle, comfortable to hold and easy to clean
• Autoclavable handpiece

Key Specifications

• Air Pressure: 180-250 KPa (1.8-2.5 kgf/cm²)
• Gas Consumption: ≥1.5 L/min
• Noise: ≤70 dB
• Rotation Range: 380,000 – 450,000 rpm
• Cooling Water Pressure: 0.2 MPa
• Max Length of Non-Rotation Part: 13.14 mm
• Handpiece Head Diameter: ø11.2 mm
• Compatible Diamond Bur: ISO1797-1 Type 3 ø1.59-1.6 mm
• Compatible Diamond Bur Length: 21–23 mm
• Handpiece Connect Method: ISO 9168, YY/T 0514
• Torque Parameter: ≥0.016 Nm

Sterilization

• Brush off excess dirt and wipe clean with alcohol-soaked cloth
• Insert the handpiece in a sterilization pouch and seal it
• Autoclavable up to 134°C
• Resistant to at least 250 cycles of high-temperature sterilization and disinfection

Lubrication

• Use oil spray or other standard oil spray after each use and/or before autoclaving

Packaging

• 1 x Airotor Handpiece
